TP-Link TL-WPA8630 - Page 13

10
Chapter 2
Initial Use
Powerline
Existing Powerline Extender New Powerline Extender
2. Join the new powerline extender into the existing powerline
network by Pairing two powerline devices.
a . Press the Pair button on the existing powerline extender
for 1 second. The Power LED starts blinking.
Note: If the Power LED does not blink, press again.
b . Within two minutes, press the Pair button on the new
powerline extender for 1 second. The Power LED starts
blinking. When the Powerline LED stays on, the pairing
process is done!
Powerline
Existing Powerline Extender New Powerline Extender
LED PairWi-Fi
LED PairWi-Fi
3. Relocate the new powerline extender to where Wi-Fi is
preferred.
Note: A red Powerline LED indicates poor signal strength, we recommend
another location.
