TP-Link TL-WR2543ND - Appendix C: Specifications

TL-WR2543ND 450Mbps Dual-Band Wireless N Gigabit Router
- 119 -
Appendix C: Specifications
General
Standards
IEEE 802.11n, IEEE 802.11g, IEEE 802.11b, IEEE 802.11a, IEEE
802.11e, IEEE 802.11i, IEEE 802.1X, IEEE 802.3X, IEEE 802.3,
IEEE 802.3u, IEEE 802.3ab
Protocols TCP/IP, PPPoE, DHCP, ICMP, NAT, SNTP
Ports
One 10/100/1000M Auto-Negotiation Internet RJ45 port, Four
10/100/1000M Auto-Negotiation LAN RJ45 ports supporting Auto
MDI/MDIX, One USB port supporting storage/FTP/Media/Print
Server
10BASE-T: UTP category 3, 4, 5 cable (maximum 100m)
EIA/TIA-568 100Ω STP (maximum 100m)
100BASE-TX: UTP category 5, 5e cable (maximum 100m)
EIA/TIA-568 100Ω STP (maximum 100m)
Cabling Type
1000BASE-TX: UTP category 5, 5e cable (maximum 100m)
EIA/TIA-568 100Ω STP (maximum 100m)
LEDs
Power, Wireless 2.4GHz, Wireless 5GHz, LAN (1-4), Internet, USB,
WPS
Safety & Emissions FCC, CE
Wireless
Frequency Band*
2.4～2.4835GHz，5.15～5.25GHz，5.725～5.825GHz
Radio Data Rate
11b：1/2/5.5/11Mbps
11a/g：6/9/12/18/24/36/48/54Mbps
11n：up to 450Mbps
Frequency Expansion DSSS (Direct Sequence Spread Spectrum)
Modulation
11n/g/a：QPSK,BPSK,16-QAM,64-QAM for OFDM
11b：CCK,DQPSK,DBPSK
Security WEP/WPA/WPA2/WPA2-PSK/WPA-PSK
Sensitivity @PER
1M：-90dBm@8%PER
11M：-85dBm@8%PER
6M：-88dBm@10%PER
54M：-68dBm@10%PER
65M/130M/195M：-67dBm@10%PER
135M/270M/415M：-64dBm@10%PER
Antenna Gain
2dBi@2.4-2.5GHz，3dBi@4.9-5.825GHz
Environmental and Physical
Operating : 0℃~40℃ (32 ~104℉℉)
Temperature.
Storage: -40℃~70℃ (-40℉~158℉)
Operating: 10% - 90% RH, Non-condensing
Humidity
Storage: 5% - 90% RH, Non-condensing
* Only 2.412GHz~2.462GHz is allowed to be used in USA, which means only channel 1~11 is available for
American users to choose.
