10
MT0333 959mm
x6
Fix using top
holes
Fix using
bottom holes
Fix using
bottom holes
F
A3839M
M6 x 12mm
x12
F
A3839F
inc Spring Washer
M8 x 24mm
x
12
13
TP Explorer Climbing Set with Platform & Den
TP843 Explorer Frame Set Inst 5012 -B 10 15.qxp_TP843 Explorer Frame Set Inst 5012-B 10 15 19/10/2015 11:38 Page 13
