11
TP Triple Round Wood Multiplay
Stage
7
M8 x25mm
Washer
FA8440
x8
M8 x 120mm Bolt x4
FA9771
M8
Nylon Insert Nut
FA5174
x4
Stage
8
70mm Coachscrew x4
FA8439
Drill 5mm
Pilot holes
ASSEMBLY TIP
Step
ladders
required.
Fully tighten these
4 bolts.
IMPORTANT
ASSEMBLY TIP
TP814 Roundwood Triple Multiplay NEW In0814-D 25.09.17.indd 11 25/09/2017 10:41
