TP Toys active fun TP814 - Stage 9: Deck Board Installation; Spacing Deck Boards

12
TP Triple Round Wood Multiplay
Stage
9
4.5 x 40mm Woodscrew x28
FA4517
Deckboards - Spacing
Space evenly with a minimum gap of 13mm between boards
Swing Arm End
Roundwood Multiplay Deck Boards x14
MW0223 700mm
13mm
13mm
IMPORTANT
ASSEMBLY TIP
DECKBOARD
COULD OVERHANG
HERE SLIGHTLY
SLIDE END
TP Branding Badge
to face SLIDE END
of Platform
ASSEMBLY TIP
