TP Toys active fun TP814 User Manual

20
TP Triple Round Wood Multiplay
Stage
18
350mm
Min
Stage
19
Glider Downtube Bottom x2
MT0521
Glider Seat Tubes x2
MT0522
MT0522
MT0522
MT0521
MT0521
Plastic
washer
Plastic
washer
35mm
40mm
FA2830 Male/female Bolt Set x2
M8 x 73mm
Spring
washer
IMPORTANT
ASSEMBLY TIP
All fixings should only be
done to finger tight during
assembly.
TP814 Roundwood Triple Multiplay NEW In0814-D 25.09.17.indd 20 25/09/2017 10:42
