TP Toys active fun TP814 - Stage 4: Main Leg Assembly Continuation; Ensuring Leg Orientation

9
TP Triple Round Wood Multiplay
Stage
4
Legs (Deck) x2
MW0222 2668mm
1300mm
1300mm
Ensure legs are
assembled this way.
1300mm dimension is
from the ground.
IMPORTANT
ASSEMBLY TIP
ASSEMBLY
TIP
Do not use screws
until Stage 8.
IMPORTANT ASSEMBLY TIP
TOP is stamped on the wood.
Take the pieces with TOP on them
and insert into the brackets.
IMPORTANT ASSEMBLY TIP
TP814 Roundwood Triple Multiplay NEW In0814-D 25.09.17.indd 9 25/09/2017 10:41
