TPI PM-18FO User Manual

Issue Date: 3-11-05 Rev. Date: 9-12-07 Rev. Level: 13 ECN: n/a OIPM P/N: 3420433 Page 3 of 8
SPECIFICATIONS (continued)
PM
-
18C CART ASSEMBLY & PARTS LIST
MODEL:
PM
-
18S
• One 18-inch fan head with white powder-
coated
guard mou
nted on a yoke attached to the pump
enclosure.
•
An integral ground fault circuit interrupter (GFCI) is
attached to the power cord.
• Equipped with a power cutoff tip switch.
• One extra nozzle and two plugs included.
• A 10-gallon Igloo cooler is included for use
as water
reservoir.
• Shipped in two cartons and ready to assemble.
MODEL:
PM
-
18C
• One 18-inch fan head with white powder-
coated guard
mounted on a yoke that attaches to the cart mast.
• The cart base is supplied with two 10-
inch wheels and
a tray. (Customer assembly of these components is
required. See assembly instructions on page 4.)
•
An integral ground fault circuit interrupter (GFCI) is
attached to the power cord.
• Equipped with a power cutoff tip switch.
• One extra nozzle and two plugs included.
• A 10-
gallon Igloo cooler is included for use as water
reservoir.
• Shipped in a single carton and ready to assemble.
ITEM
NO.
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
DESCRIPTION
Mast
Washer Flat 1/4
Hex Nut 1/4-20
Bolt Carriage 1/4-20 x 1-3/4”
Base
Base Tray
Push Nut
Washer Curved
Wheel 10”
Handle Grip
Screw Hex Head 1/2-13 x 1
Washer Lock 1/2”
Screw HWH 8-32 x 3/8
Yoke
Retaining strap
Nozzle (Brass)
Plug
PART NO.
35042001
3442532
3440132
3409456
8499700
3504121
8045700
3448056
8483100
3409100
2474400
3419500
2326500
3314721
44134001
44108001
44108002
QTY.
1
8
8
8
1
1
2
2
2
1
1
1
1
1
1
5
2
11
12
14
13
1
Fan yoke / Mast assembly
16
17
