BLUE M
Blue M - - DC 146 Series Industrial Ovens, Models DC, DCW, DCI, DCC
Page 9
3.1 Application & Specifications
This manual applies to the Blue M Model 146 Series Industrial Ovens, which are designed in three distinct
types and in a wide range of sizes. They serve a very diverse number of process applications. An electric
heating system is used with a high volume air circulation system to provide maximum temperature uniformity.
Model Type Model No. Workspace Temp. Rating
Standard Models Model DC / DCW 1.6 to 24 Ft.
3
15° above ambient to 350° C
Inert Gas Models Model DCI 1.6 to 24 Ft.
3
15° above ambient to 350° C
Clean Room Models Model DCC 1.2 to 21.6 Ft.
3
15° above ambient to 250° C
 Standard DC Models are the building block to the 146 Series with a proven high quality design and
simple operation.
 Model DCW ovens are identical to the Model DC except that they incorporate a welded and sealed liner,
which creates an impervious barrier between the process chamber and the insulation material.
 Inert Gas Model DCI ovens are utilized for processing materials in an inert atmosphere using a gas
injection system. An inert atmosphere prevents oxidation from occurring on the product and eliminates
the capability of oven air from supporting a flame.
 Clean Room Model DCC ovens employ a HEPA (or ULPA) filtration system to maintain Class 100
conditions in the oven workspace. An inert atmosphere is also maintained in the Model DCC.
 Model DCI and DCC ovens are constructed with an interior that is welded vapor tight. Special seals are
installed on the door, blower shaft, and heater element terminals to ensure the sealed integrity.
Workspace Capacity:
A size code is given in the model number to indicate workspace capacity. Refer to the chart below.
Important! For custom ovens
with sizes not listed in this chart,
the workspace will be given below.
For S/N xxxxxxxxxx, O/N xxxxx,
Model DCxxx, the workspace
capacity is xxx cubic feet.
3.0 PRODUCT SPECIFICATIONS & OVERVIEW
WORKSPACE CAPACITY - SIZE CODE CHART
MODEL DCxxx, WHERE xxx = SIZE CODE
SIZE CODE CAPACITY (CUBIC FEET)
146 1.6
206 4.2
256 5.8
136 11.0
336 11.0
1406 24.0
1506 20.0
