TQ Environmental Limited
Page 7 of 43 17654PM Issue: 3 December 2022
1.1 Specification
Inputs:
Std 8 x 2/3 wire 4-20mA source, or 3 wire Pellistor type.
Expandable up to 48 inputs
Outputs: 16 SPCO relays, rating: 24 Vdc/280V ac @ 12A resistive local
in Panel
32 SPCO relays, rating: 24 Vdc/280V ac @ 12A resistive local
or external to panel
1 x 4-20mA source per input. (non-isolated)
RS485 MODBUS protocol. Baud rate
Alarms: 3 alarm levels per channel, adjustable to any point within the
full-scale range.
Power Supply: Universal; 85 to 254 volts ac 50/60Hz (24v dc on request) @
65VA - 8 Chanel,
150VA - 16 Chanel,
225VA - 24 Chanel,
300VA - 32 Chanel.
375VA - 40 Chanel.
IP54
Enclosure: ABS Box, RFI coated.
Bottom gland plate.
Display: 7” TFT HDMI Display with Touch Screen Controller
80dB
Dimensions: This depends on the number of channels and client
requirements. Below are some typical dimensions:
8-channel: 341mm high x 326mm wide x 160mm deep
16-channel: 600mm high x 600mm wide x 250 mm deep
24-32 channel: 1000.0mm high x 600.0 mm wide x 250.0 mm
