Trace2O METALYSER HM1000 User Manual

28 www.trace2o.com
Metalyser
®
Portable HM1000 Instruction Manual v 5.0
9. SPECIFICATIONS
Metalyser
®
HM1000 Handheld Unit
Environment Water Ingress: IP67
Operating temp: -20ºC to +70ºC
Storage temp: -20 ºC to + 70 ºC
Connections 1 x waterproof Mini USB port, 1 x 12 Way Multipole
Connector.
Display 128 x 128 pixel monochrome backlit LCD.
Power supply 4.5 – 5V DC, 700mAh
Battery 3.3V Li-ion 2200mAh rechargeable.
Parameter
Lower Limit
⁺
Upper Limit*
Arsenic (III)
As (III)
5
500
Total Arsenic
As (III+V)
10
500
Copper
Cu
5
500
Mercury
Hg
5
500
Cadmium
Cd
3
500
Lead
Pb
5
500
Zinc
Zn
5
500
*Upper limit fixed at 500ppb. If the user requires values higher than this then a
dilution will be needed
⁺
Lower limits achievable using the Handset at 60 seconds deposition.
Increased accuracy can be achieved by setting the deposition time to 120 seconds
Variability at 20ppb ± 5% with Metaware software, ± 7.5% with handheld
Accuracy dependent on element measured, sample matrix and type

Trace2O METALYSER HM1000 Specifications
