Trafomatic Audio Experience TWO - Technical Specifications

59
9
Integrated tube amplier
Maximum output power:8W
Class of operation: A
THD: 0.8%max(1W/1kHz)
Bandwidth:10Hz(-1dB)-45kHz(-3dB)
Inputs: CD, Tuner, Aux
Input sensitivity:0.5Vpk
Input impedance: 100 kOhm
Output (speaker) impedance: Speaker terminals for 4 and 8 ohms
Tubes: 2x6SN7,2x300B,1x5U4G
Input Voltage:120V,60Hzor230V,50Hz(asmarkedontherealplate)
Maximum input current:3Aat120V,1.5Aat230V
Dimensions:
Width x Depth x Height:430mmx300mmx200mm(17”x12”x8”)
Weight: 20kg(44lbs)
Trafomatic Audio
Trafomatic Audio
Experience Two
Technical Specications:
