Operating Procedure
1.Makesurethatyoureadinstructionsbeforeattemptingtooperateyourunit.
2.Attachtheaudiosourcesandspeakers(refertothepicturebelow).
Never run the amplier without speakers connected since that may damage the transformers.
Speaker’sminusterminalshouldbeconnectedtothespeakerterminalmarkedaszero(0)andpositivetermi-
nalshouldbeconnectedtotheterminalthatcorrespondstothespeaker’snominalimpedance(4or8ohms).
Ifyourspeakerhasnominalimpedanceof6ohms,youcanconnectittoeitherofthetwooutputs.Youshould
trybothandselecttheonethatperformsbetterwithyourspeakers.Makesuretopreventshortcircuitatthe
amplier’sspeakerterminalsasthatwilldamagetheamplier
Figure 2: Experience Two speakers connection
NOTE: 4 ohms and 8 ohms speakers cannot be connected to the speaker terminals at the same time!
Makesureyouramplierisproperlyconnectedtoahigh-currentpowerreceptacle.
3.Whenturningtheuniton,makesurethevolumecontrolisatitslowestpoint(thevolumecontrolisatmini-
mumwhenturnedcounterclockwisetothemechanicallimit).
4.Theamplierwillbefullyfunctionalafteronlyacoupleofminutes.However,asitwarmsupovertherst30
minutes of operation you may notice slight improvement in the sound quality.
5.Attheendofyourlisteningsessionmakesuretoturntheamplieroff.Leavingitondoesnothingforsound
quality and it reduces life of the vacuum tubes.
The amplier should always be turned on and off via its own power on-off switch.
Trafomatic Audio
Trafomatic Audio
Experience Two
right
left
CD TUNER AUX
TRAFOMATIC LTD, Serbia
www.trafomatic.com
0 4 80 4 8
right
left
230V/50Hz
1.5Amp
120V/50Hz
3Amp
Made in Serbia
Serial No.
