Operation controls
Operate accelerator, brake and other controlling parts of this electric kart
without looking. Please learn carefully the following diagram and be familiar
with the functions and position of each control part.
1 ANTI-ROLL BAR 8 FRONT
ARM ,L
2 SEAT 9 PROTECTING BAR
3 STERING WHEEL 10 FRONT LOWER SUSPENS
ARM ,R
4 UPPER SUSPENSION ARM 11 CUSHION ASS'Y. FR
5 STEERING GEAR ASSY 12 FR.WHEEL ASSY.R
6 SPINDLE AND STRUT SUPPORT,L 13 SPINDLE AND STRUT SUPPORT,R
7 FR.WHEEL ASSY.L
