Tension of drive chain
The drive chain transfers the power from motor to rear wheels. In order to
ensure the normal work, it must be lubricated and tensioned at all times.
Check the tension of the drive chain by vertical movement of half distance
between sprockets. The vertical slack of more than 1/2 inch is not allowed
between drive chains. The drive chain is likely to fall if slack in riding.
To adjust the tension of drive chain, below steps should be followed:
1. Ensure the kart parks on smooth ground with a
single support.
2. Loosen the spindle nut on both side of rear wheel
with a wrench of 15mm.
3. After spindle nut loosened, rotate the tensioner
bolt clockwise beside sprocket with a
10mm, and then repeat the action to the tensioner
bolt on the other side of sprocket.
4. Check the tension of drive chain.
Check if the tension reaches ideal level. If not, repeat steps 3 and 4 until
requirement has been met.
5. Tighten axle bolt to 15 foot-pounds.
Note: To loosen the drive chain tension, follow the above steps, except this
step that loosen the tensioner bolt clockwise.
Lubrication of drive chain
The drive chain of the vehicle should be often lubricated to prevent excessive
wear. Below steps should be followed:
