Name of each part

1 ANTI-ROLL BAR 8 FRONT

LOWER SUSPENSION

ARM ,L

2 SEAT 9 PROTECTING BAR

3 STERING WHEEL 10 FRONT

LOWER SUSPENSION

ARM ,R

4 UPPER SUSPENSION ARM 11 CUSHION ASS'Y. FR

5 STEERING GEAR ASSY 12 FR.WHEEL ASSY.R

6 SPINDLE AND STRUT SUPPORT,L 13 SPINDLE AND STRUT SUPPORT,R

7 FR.WHEEL ASSY.L
