25
It is necessary to tap the plastic cap
all the way onto the bar. Use a plastic
or rubber mallet or a block of wood with a
standard hammer.
26
Install the top bolt & washer first.
Start the threads but do not tighten.
27
Now, install the bottom bolt and
washer from the front.
28
Install the second washer and nut on
the bottom bolt.
NOTE: DO NOT TIGHTEN THE HARDWARE.
29
Repeat steps 21-28 for the driver’s
side bar.
30
Locate the top bar weldment assem-
bly.
