Unit Components
Note: Components are identified from a viewpoint that faces the front side of the control panel.
Figure 2. Typical CVHF CenTraVac Chiller
1
2
3
11
4
5
6
7
8
9
10
1. Suction Elbow
2. Compressor
3. Terminal Box
4. Control Panel
5. Condenser
6. Motor Housing
7. Economizer
8. Oil Tank Assembly
9. Purge
10. Evaporator
11. Display Panel
TCVHE-SVX04D-EN 11
