Trane Technologies CVHE - Page 13

The weight information provided here should be used
for general information purposes only. Trane does not
recommend using this weight information for consid-
erations relative to chiller handling. The large number
of variances between chiller selections drives variances
in chiller weights that are not recognized in this table.
For specific weigts for you chiller refer to your submittal
package.
These values represent chiller weights do not include the
following:
• TECU 0.028” tubes
• 150 psig non-marine waterboxes
• INDP (Industrial Control Panel), add 50 lb (23kg)
• CPTR (Control Panel Transformer) option, add 130 lb
(50 kg)
• SMP (Supplemental Motor Protection) option, add
500 lb (230 kg)
• Operating weights include the heaviest possible
refrigerant charge weight
• Chillers with starter values include the weight of the
heaviest possible starter
• Heaviest possible bundle and heaviest possible mo-
tor voltage combination for the applicable family of
chillers
Table 1. Unit Weights
Without Starters With Starters
Operating Weights Shipping Weights Operating Weights Shipping Weights
MODEL NTON CPKW EVSZ CDSZ lb kg lb kg lb kg lb kg
C
V
H
F
350–570 588 050L 050L 21152 9595 18617 8445 222234 10085 19699 8935
350–570 588 050S 060L 19814 8988 17668 8014 20896 9478 18750 8505
350–570 588 060S 050S 18925 8584 16937 7683 20007 9075 18019 8173
350–570 588 080L 080L 30751 13949 26866 12186 31833 14439 27948 12677
350–570 588 080S 080L 28589 12968 25254 11455 29671 13459 26336 11946
350–570 588 080S 080S 26876 12191 23787 10790 27958 12682 24869 11281
650–910 957 080L 080L 32688 14827 28803 13065 34249 15535 30364 13773
650–910 957 080S 080L 30526 13847 27191 12334 32087 14555 28752 13042
650–910 957 080S 080S 2883 13070 25724 11668 30374 13778 27285 12376
650–910 957 142L 142L 42739 19386 36476 16546 44300 20094 38037 17254
650–910 957 142M 142L 41548 18846 35653 16172 43109 19554 37214 16880
1070–1300 1228 142E 142L 44647 20252 37997 17235 46064 20894 39414 17878
1070–1300 1228 142L 142L 43370 19672 37107 16831 44787 20315 38524 17474
1070–1300 1228 142M 142L 42179 19132 36284 16458 43596 19775 37701 17101
1070–1300 1228 210L 210L 52816 23957 44810 20325 54233 24600 46227 20968
1470 1340 210L 210L 56217 25500 48211 21869 57299 25991 49293 22359
1470–1720 1340 250E 250L 68393 31023 57807 26221 69475 31514 58889 26712
C
V
H
E
230–320 287 032L 032L 16691 7571 15145 6870 17773 8062 16227 7361
230–320 287 032S 032L 15795 7165 14484 6570 16877 7655 15566 7061
230–320 287 032S 032S 14960 6786 13730 6228 16042 7277 14812 6719
230–320 287 060L 060L 20650 9367 18081 8202 21732 9858 19163 8692
230–320 287 050S 050L 19312 8760 17132 7771 20394 9251 18214 8262
230–320 287 050S 050S 1278 8291 16248 7370 19360 8782 17330 7861
360–500 453 050L 050L 22187 10064 19618 8899 23269 10555 20700 9390
360–500 453 050S 050L 20849 9457 18669 8468 21931 9948 19751 8959
360–500 453 050S 050S 19815 8988 17785 8067 20897 9479 18867 8558
360–500 453 080L 080L 30758 13952 26806 12159 31840 14443 27888 12650
360–500 453 080S 080L 18595 12971 25194 14428 29677 13461 26276 11919
360–500 453 080S 080S 27155 12318 24016 10894 28237 12808 25098 11384
