Trane Technologies CVHE - Page 76

CVHF 1070
100 78 77 76 74 77 73 71 65
75 72 73 75 72 73 69 69 67
50 76 74 75 72 72 67 66 68
25 72 73 74 72 71 66 66 69
CVHF1300
100 78 78 79 77 80 75 72 65
75 77 77 77 74 76 72 69 66
50 77 76 75 73 73 68 66 68
25 77 75 75 74 73 69 66 68
CVHF 1470
100 79 79 79 78 79 77 74 65
75 79 77 78 77 75 72 65 66
50 76 76 77 75 74 71 68 66
25 79 78 77 74 71 68 67 66
CVHF 1720
100 76 80 79 78 80 78 75 64
75 76 77 77 76 78 74 70 66
50 77 79 79 75 73 69 66 67
25 77 79 79 75 73 71 67 69
CDHF 1500
100 78 78 82 80 80 76 72 65
75 77 78 81 81 80 76 71 64
50 76 79 79 81 80 75 71 63
25 76 79 78 83 80 75 70 62
CDHF 2000
100 80 82 81 81 80 76 72 69
75 80 79 81 79 78 74 71 68
50 81 79 80 76 73 70 68 70
25 80 79 80 77 74 70 69 68
CDHF 2170
100 79 79 80 79 83 77 74 68
75 76 79 78 77 78 75 71 68
50 76 78 79 77 75 73 70 71
25 77 79 80 77 75 71 69 70
CDHF 2550
100 77 82 82 80 83 80 75 68
75 77 80 81 79 81 78 73 68
50 77 79 80 78 80 76 71 69
25 76 79 80 77 79 76 70 68
60 Hz sound pressure (dB) by octave band with AHRI relief and Adaptive Frequency™ drive (AFD) (continued)
Model % Load 63 Hz 125 Hz 250 Hz 500 Hz 1000 Hz 2000 Hz 4000 Hz 8000 Hz
TCVHE-SVX04D-EN 76
