Operating Ranges
Connection Pipe Requirements
Heating Operating Range Outdoor Temperature -4 - 75°F (-20 - 24°C)
Cooling Operating Range Outdoor Temperature 0 - 115°F (-18 - 46°C)
Indoor Operating Range Indoor Temperature 61 - 86°F (16 - 30°C)
10
23 Series Single Zone
NOTICE
The maximum distance of the connection piping in both height and total length is provided in the
table below. Do not install these units in locations that exceed these specifications.
NOTES:
1. The connection pipes should be insulated with proper water-proof insulating material
2. Use type ACR copper piping.
3. Shorter connecting pipe lengths result in greater thermal efficiency, so it is preferable to reduce
connecting pipe lengths where possible.
4. Refer to the oil trap instructions for specific requirements when there is height difference
between the indoor and outdoor unit greater than 20 ft. (6m).
Heat Pump
4TXK2309 4TXK2312 4TXK2318 4TXK2324 4TXK2330 4TXK2336
4MXW2309 4MXW2312 4MXW2318 4MXW2324 4MXW2330 4MXW2336
Refrigerant Charge (oz.) 46 48 56 78 85 92
Standard Length ft (m) 25 (7.6)
Additional Refrigerant Charge (oz/ft)
For Piping Beyond Standard Length
0.22 0.2 0.5
Outer Diameter
Liquid Pipe in. (mm) Φ 1/4" (6.35)
Gas Pipe in. (mm) 3/8" (9.525) Φ 1/2" (12.7) 5/8" (15.875)
Max Distance
Height ft. (m) 55 (16.76)
Length ft. (m) 100 (30.5) 130 (39.6)
Minimum Piping Length ft. (m) 10 (3)
Compressor Oil Used
DAPHNE FVC50K
(PVE Oil)
RB68EP (POE Oil)
FV50S
(PVE Oil)
