Part 4 Indoor Units - One way Cassette
4.1 Specication
TRANE Model
IDU 4MXE2309BF0W0AA 4MXE2312BF0W0AA
Panel 4MXM2312BF0W0AA 4MXM2312BF0W0AA
Power supply V-ph-Hz 220-1-50(60) 220-1-50(60)
Cooling
Capacity Btu/h 8,500 12,000
Capacity W 2,500 3,500
Heating
Capacity Btu/h 9,000 12,000
Capacity W 2,700 3,500
Indoor fan motor
Model ZWK465B500015 ZWK465B500015
Qty 1 1
Input W 88 88
Capacitor uF / /
Speed(Hi/Med/Lo) r/min 870/800/700/600/550 950/870/800/700/600
Indoor coil
Number of rows 2 2
Tube pitch(a)x row pitch(b) mm 21×13.3 21×13.3
Fin spacing mm 1.4 1.4
Fin type Hydrophilic aluminum Hydrophilic aluminum
Tube outside dia.and type mm Φ7 Φ7
Coil length × height × width mm
675×168×13.3&
675×84×13.3
675×168×13.3&
675×84×13.3
Number of circuits 12 12
Indoor air ow (Hi/Med/Lo) m
3
/h 500/460/420 530/500/460
Indoor noise level (sound pressure) (Hi/Med/Lo) dB(A) 34/30/26 36/32/28
Throttle type / /
Indoor unit
Dimension (W × D × H) (body) mm 875×505×185 875×505×185
Packing (W × D × H) (body) mm 1,028×581×270 1,028×581×270
Dimension (W × D × H) (panel) mm 1,050×560×122 1,050×560×122
Packing (W × D × H) (panel) mm 1,133×623×197 1,133×623×197
Net/Gross weight (body) kg 15.3/17.9 15.3/17.9
Net/Gross weight (panel) kg 5.3/8.3 5.3/8.3
Design pressure MPa 4.15 4.15
Drainage water pipe diameter mm Φ32 Φ32
Refrigerant piping Liquid side/Gas side mm (inch) Φ6.35/Φ9.52 Φ6.35/Φ9.52
Controller Remote control Remote control
Operation temperature °C 16~30 16~30
Room temperature
Cooling °C 18~32 18~32
Heating °C 15~27 15~27
Qty’per 20’ /40’ /40'HQ (indoor unit) 100/200/230 100/200/230
