Trane 4TXM2318BF300AA User Manual

4
TRANE Model
IDU 4MXC2318BF0W0AA 4MXC2324BF0W0AA
Panel 4MXL2318BF0W0AA 4MXL2324BF0W0AA
Power supply V-ph-Hz 220-1-50(60) 220-1-50(60)
Cooling
Capacity Btu/h 17,000 24,000
Capacity W 5,000 7,000
Heating
Capacity Btu/h 18,000 24,000
Capacity W 5,300 7,000
Indoor fan
motor
Model ZW465C03 ZWK465B500011
Qty
1 1
Input w 33 72
Capacitor uF / /
Speed(hi/mi/lo) r/min 800/700/600 500/400/300
Indoor coil
a.Number of rows
2 2
b.Tube pitch(a)× row pitch(b) mm 21×13.3 21×13.3
c.Fin spacing mm 1.25 1.4
d.Fin type (code)
Hydrophilic aluminium Hydrophilic aluminium
e.Tube outside dia.and type mm Ф7,innergroove tube Ф7,innergroove tube
f.Coil length × height × width mm 1,330×210×26.6 2,242×168×26.6
g.Number of circuits
10 8
Indoor air ow (Hi/Med/Lo) m 700/620/500 1,260/1,070/820
Sound level (sound pressure) dB(A) 42/37/35 36/33/29
Throttle type
/ /
Indoor unit
Dimension (W × D × H)(body) mm 570×570×260 840×840×204
Packing (W × D × H)(body) mm 718×680×380 990×990×310
Dimension (W × D × H)(panel) mm 620×620×60 950×950×50
Packing (W × D × H)(panel) mm 660×660×115 1,000×1,000×110
Net/Gross weight(body) kg 19/22 27/31
Net/Gross weight(panel) kg 2.8/4.8 6.5/9
Design pressure MPa 4.15 4.15
Drainage water pipe dia. mm PVC 26/32 PVC 26/32
Refrigerant
piping
Liquid side/ Gas side mm Φ6.35/Φ12.7 Φ9.52/Φ15.88
Controller
Remote control Remote control
Operation temperature
℃
16~30 16~30
Room
temperature
Cooling
℃
18~32 18~32
Heating
℃
15~27 15~27
Qty’per 20’ /40’ /40'HQ 118/240/284 55/125/144
