Trane 4TXM2318BF300AA - Page 68

66
TRANE Model 4TXM2330BF400AA 4TXM2336BF500AA
Power supply
V-ph-Hz 220-1-50(60) 220-1-50(60)
Max. IDU combination
4 5
Max. input consumption
W 4,100 4,300
Max. input current
A 17.8 18.8
Cooling
Capacity
Btu/h 29,000 35,000
Capacity
W 8,500 10,255
Input
W 2,900 3,420
Rated Current
A 13.1 15.2
EER
W/W 3.00 3.00
Heating
Capacity
Btu/h 30,000 36,000
Capacity W 8,800 10,500
Input
W 2,500 3,600
Rated Current
A 11.2 14.1
COP
W/W 3.4 3
Compressor
Model
TNB220FLHMC TNB220FLHMC
Type
Twin Rotary (DC inverter) Twin Rotary (DC inverter)
Brand
MELCOM MELCOM
Capacity
Btu/h 24,000 24,000
Input
W 2,200 2,200
Rated current(RLA)
A 9.7 9.7
Locked rotor Amp(LRA)
A 45 45
Thermal protector position
INTERNAL INTERNAL
Capacitor
μF / /
Refrigerant oil
ml 870 870
Outdoor fan motor
Model
ZWK511B500045 ZWK511B500045
Qty
1 1
Input
W 130 130
Capacitor
μF / /
Speed
r/min 770 800
Outdoor coil
Number of rows
2
2
Tube pitch(a) × row
pitch(b)
mm 21×18.18 21×18.18
Fin spacing
mm 1.4 1.4
Fin type
Hydrophilic aluminium Hydrophilic aluminium
Tube outside dia.and type
mm TP2M /7 TP2M /7
Coil length × height ×
width
mm 950×651×36.36 940×714×36.36
Number of circuits
5 6
