Optional Equipment
BAYCURB050A FULL PERIMETER ROOF MOUNTING CURB FOR *****024-036
46 3/8
17 7/8
3
3 5/8
19 1/2
2 3/16
19 1/2
14
1 1/2
38 7/8
15
35 7/8
43 3/8
