14
18-GF16D1-1A-EN
Table 9. Air Flow Performance
A4AH4E48B1C30A, A4AH4E60B1C30A
EXTERNAL STATIC
(in w.g)
AIRFLOW
Speed Taps: 208 – 230 VOLTS
High Med-High
Med † Med-Low Low
0.1 2040 1874 1658 1512 1373
0.2 2008 1846 1622 1476 1333
0.3 1975 1816 1585 1438 1289
0.4 1942 1785 1546 1395 1240
0.5 1909 1751 1506 1349 1187
0.6 1875 1716 1463 1300 1129
0.7 1841 1678 1418 1246 1067
1. Values are with wet coil, no filter, and no heaters
2. CFM Correction for dry coil = Add 3%
3. † = Factory Setting
4. In downflow applications, airflow must not exceed 1800 cfm due to condensate blowoff.
5. Low = Tap 1, Med-Low = Tap 2, Med = Tap 3, Med-High= Tap 4, High = Tap 5
Table 10. Electrical Data
A4AH4E48B1C30A, A4AH4E60B1C30A
Heater Model No.
No. of
Circuits/
Phases
240 Volt 208 Volt
Capacity Heater
Amps
per
Circuit
Minimum
Circuit
Ampacity
Maximum
Overload
Protec-
tion
Capacity Heater
Amps
per
Circuit
Minimum
Circuit
Ampacity
Maximum
Overload
ProtectionkW BTUH kW BTUH
No Heater 6.0 * 8 15 6.0 * 8 15
BAYHTR1504BRK
BAYHTR1504LUG
1/1 3.8 13100 16.0 28 30 2.9 9800 13.8 25 25
BAYHTR1505BRK
BAYHTR1505LUG
1/1 4.8 16400 20.0 33 35 3.6 12300 17.3 29 30
BAYHTR1508BRK
BAYHTR1508LUG
1/1 7.7 26200 32.0 48 50 5.8 19700 27.7 42 45
BAYHTR1510BRK
BAYHTR1510LUG
1/1 9.6 32800 40.0 58 60 7.2 24600 34.6 51 60
BAYHTR1517BRK-
Circuit 1
(a)
2/1
9.6 32800 40.0 58 60 7.2 24600 34.6 51 60
BAYHTR1517BRK-
Circuit 2
4.8 16400 20.0 25 25 3.6 12300 17.3 22 25
BAYHTR1523BRK-
Circuit 1
2/1
9.6 32800 40.0 58 60 7.2 24600 34.6 51 60
BAYHTR1523BRK-
Circuit 2
9.6 32800 40.0 50 50 7.2 24600 34.6 43 45
BAYHTR1525BRK-
Circuit 1
4/1
6.0 20500 25.0 39 40 4.5 15400 21.6 35 35
BAYHTR1525BRK-
Circuit 2
6.0 20500 25.0 31 35 4.5 15400 21.6 27 30
BAYHTR1525BRK-
Circuit 3
6.0 20500 25.0 31 35 4.5 15400 21.6 27 30
BAYHTR1525BRK-
Circuit 4
6.0 20500 25.0 31 35 4.5 15400 21.6 27 30
PPeerrffoorrmmaannccee aanndd EElleeccttrriiccaall DDaattaa
