Trane A4AH4E36A1C30A - Heater Pressure Drop Table

18
18-GF16D1-1A-EN
Heater Pressure Drop Table
Airflow
CFM
Number of Racks Heater Racks
1 2 3 4 Heater Model No. of Racks
Air Pressure Drop — Inches W.G.
BAYHTR1504 1
1800 0.02 0.04 0.06 0.14 BAYHTR1505 1
1700 0.02 0.04 0.06 0.14 BAYHTR1508 2
1600 0.02 0.04 0.06 0.13 BAYHTR1510 2
1500 0.02 0.04 0.06 0.12 BAYHTR1517 3
1400 0.02 0.04 0.06 0.12 BAYHTR3510 3
1300 0.02 0.04 0.05 0.11 BAYHTR3517 3
1200 0.01 0.04 0.05 0.10 BAYHTR3515 3
1100 0.01 0.03 0.05 0.09 BAYHTR1523 4
1000 0.01 0.03 0.04 0.09 BAYHTR1525 4
900 0.01 0.03 0.04 0.08
800 0.01 0.03
700 0.01 0.02
600 0.01 0.02
