18-GF16D1-1A-EN
25
Figure 14. A4AH4E24 — Front view
Note: 180 degree rotation of top baffle not required for coils without
top cap tabs.
Top Cap
Snap
Tab
Feature
Remove 2 screws
and water diverter
bracket
Figure 15. A4AH4E24 — Front view
Top Cap
Snap
Tab
Feature
Replace 2 screws
and water diverter
bracket
Figure 16. A4AH4E24 — Rear view
Remove 2 screws
and water diverter
bracket
Snap Tab
Feature
Top Cap
Figure 17. A4AH4E24 — Rear view
Replace 2 screws
and water diverter
bracket
Snap Tab
Feature
Top Cap
CCooiill CCoonnvveerrssiioonn IInnssttrruuccttiioonnss
