4 18-CD31D1-3
Installer’s Guide
From Dwg. 21C341699 Rev. 4
*UD2-9V OUTLINE DRAWING
(ALL DIMENSIONS ARE IN INCHES)
MODEL DIM "A" DIM "B" DIM "C" DIM "D"
*UD2B060A9V3VB
*UD2B080A9V3VB
*UD2B100A9V3VB
17-1/2" 9-5/8" 16-1/4" 16"
*UD2C080A9V4VB
*UD2C080B9V4VB
*UD2C100A9V5VB
*UD2C100B9V5VB
21" 13-1/16" 19-3/4" 19-1/2"
*UD2D120A9V5VB
*UD2D120B9V5VB
*UD2D140A9V5VB
24-1/2" 15-5/16" 23-1/4" 23"
* - The First Letter May Be "A" or "T"
