Service Facts
NOTE: Turn thermostat to
Emergency Heat and raise set-
point at least 5 degrees above
actual room temperature.
Troubleshooting Communicating EHC
Fault Code #5 – CTCO Open Error
Is ~13.8VDC
measured across
terminals T11 – T12?
CTCO circuit is
good
NO
Disconnect all power
sources from air handler
Using ohm meter, is
zero ohms measured
across the CTCO?
Remove wiring
from CTCO
Replace CTCO
Check operation
NO
Check CTCO circuit wiring.
Repair/replace as needed
YES
CTCO label is WHITE
NTCO label is BLUE
