10 CGWF-SVX01A-EN
General Information
CIOP 21 Control input options
NONE N No options
REMS R Remote chilled water setpoint input
REMC C Remote compressor inhibit and/or icemaking input
REMB B Remote CWS and compressor inhibit/icemaking
input
COOP 22 Control output options
NONE N No options
PROG P Programmable relays for remote alarm, run, etc.
SENS 23 Auxiliary sensor options
NONE 0 None
CDWT 1 Condenser water temp sensors (CGWF only)
AMB 2 Outdoor temp sensor - CWR or Amb Lockout
BOTH 3 Both condenser and outdoor temp sensor
COMM 24 Communication options
NONE 0 None
COM3 3 Tracer Summit interface
LCIC 5 LonTalk LCI-C interface
HGBP 25 Hot gas bypass
NONE N NO HGBP valve/function
WITH H HGBP function included
SATT 26 Sound attenuator
NONE 0 No sound attenuator
WITH 1 Sound attenuator - Fact installed
SACC 27 Ship-with accessories - isolators, WRV,
Filter-driers
NONE X No ship-with accessories
NIS0 N Neoprene isolators
WRVA A 1.5" 2-way water reg valve x 1 (CGWF only)
WRVB B 2" 2-way water reg valve x 1 (CGWF only)
WRVC C 2.5" 2-way water reg valve x 1 (CGWF only)
WRVD D 1.5" 2-way water reg valve x 2 (CGWF only)
WRVE E 2" 2-way water reg valve x 2 (CGWF only)
WRVF F 2.5" 2-way water reg valve x 2 (CGWF only)
WRAN G Neo isolators + 1.5" WRV x 1 (CGWF only)
WRCN H Neo isolators + 2" WRV x 1 (CGWF only)
WREN J Neo isolators + 2.5" WRV x 1 (CGWF only)
WRBN K Neo isolators + 1.5" WRV x 2 (CGWF only)
WRDN L Neo isolators + 2" WRV x 2 (CGWF only)
WRFN M Neo isolators + 1.5" WRV x 2 (CGWF only)
FD1 P Filter-drier x 1 (CCAF only)
FD2 Q Filter-drier x 2 (CCAF only)
NFD1 R Neo isolators + 1 Filter-drier (CCAF only)
NFD2 T Neo isolators + 2 Filter-driers (CCAF only)
SAC2 28 Ship-with accessories - flow switches
NONE 0 No flow switches
FS1 1 150 psi NEMA-1 flow switch (FS4-3) x 1
2FS1 2 150 psi NEMA-1 flow switch (FS4-3) x 2
FS4 4 150 psi NEMA-4 flow switch (FS8-W) x 1
2FS4 5 150 psi NEMA-4 flow switch (FS8-W) x 2
Table 1 Unit Model Number
FCAT FCODE M/N digit M/N value Description
