14
CVHE-SVN04M-EN
Table 5. Unit mounted starters for CVHE, CVHF, and CVHG CenTraVac chillers (continued)
Shell Size
Comp Size
Motor Size
USID, USTR UATR, UPIR, UXL, SMP USID, USTR UATR, UPIR, UXL, SMP
Y1 Y2
210
920, 1100, 1300
440E
(a)
126.6
(a)
70.1
5000
(a)
128.1
(a)
71.6
5800
(a)
129.9
(a)
73.4
1720
5000 127.4 134.1 70.9 77.6
5800
(a)
129.9
(a)
73.4
5800L
(a)
129.9
(a)
73.4
Note: All dimensions are in inches (±0.5 inch).
(a)
Does not extend beyond the main unit control panel.
Duplex Chillers: Models CDHF and CDHG
Table 6. Dimensional data for CDHF and CDHG CenTraVac chillers
Model NTON
Shell
Size
A B C D E F G H J K L M N
CDHF
1500–2000
(2-Comp)
2100 107.4 -0.2 108.2 66.6 78.5 54.3 116.0 110.9 50.2 81.0 68.9 50.5 94.2
2170 & 2550
(2-Comp)
2500 120.9 0.5 121.6 73.2 81.8 59.7 120.6 116.4 54.5 87.6 76.9 56.8 97.8
CDHG
1250–1750
(2-Comp)
2100 107.4 -0.2 108.2 66.6 95.0 54.3 116.0 110.9 50.2 81.3 68.9 50.5 94.2
2250
(2-Comp)
2100 110.5 2.7 111.3 73.2 94.2 59.7 116.0 110.9 50.5 74.7 71.9 52.4 93.8
2250
(2-Comp)
2500 120.9 0.5 121.6 73.2 94.2 59.7 120.6 116.4 54.5 79.7 76.9 56.8 94.6
CDHF
3000
(2-Comp)
250M 120.9 0.5 121.6 76.3 92.3 63.1 120.6 116.4 54.5 84.3 76.9 56.8 96.8
3500
(2-Comp)
250X 120.9 0.5 121.6 76.3 92.3 63.1 120.6 116.4 54.5 84.3 76.9 56.8 96.8
Table 7. Dimensional data for CDHF and CDHG CenTraVac chillers
Model NTON
Shell
Size
P R S T U V
AFD 900–
1210A
UAFD Low Mount Control Panel
W X Z AA BB CC DD EE
CDHF
1500–2000
(2-Comp)
2100 86.9 51.3 45.0 28.5 124.7 132.8 152.4 24.3 135.5 118.2 10.6 119.0 9.2 79.7
2170 & 2550
(2-Comp)
2500 90.9 57.5 46.0 36.8 137.2 139.3 160.0 20.2 147.2 130.9 10.5 131.6 135. 86.9
CDHG
1250–1750
(2-Comp)
2100 86.9 51.3 45.0 32.4 124.7 132.8
N/A N/A N/A N/A N/A N/A N/A N/A
2250
(2-Comp)
2100 86.9 53.2 46.0 36.8 127.7 135.4
N/A N/A N/A N/A N/A N/A N/A N/A
2250
(2-Comp)
2500 90.6 57.5 46.0 36.8 137.2 139.3
N/A N/A N/A N/A N/A N/A N/A N/A
CDHF
3000
(2-Comp)
250M 90.9 57.5 37.0 33.3 137.2 141.3 160.0 20.2 147.2 130.9 10.5 131.6 13.5 86.9
3500
(2-Comp)
250X 90.9 57.5 37.0 33.3 137.2 141.3 160.0 20.2 147.2 130.9 10.5 131.6 13.5 86.9
