Table 8. Motor terminal boxes and unit mounted starters for CDHF and CDHG CenTraVac chillers
Shell Size
Comp Size
Motor Size
Y1 USTR, USID Y2 UATR, UPIR, UXL
Y3 LV Motor Terminal Box Y3 MV Motor Terminal Box
2100
091
440E 9.7 11.4 -10.2 -0.2
5000 9.7 12.9 -8.7 1.3
078
440E 9.7 11.4 -10.2 -0.2
5000 9.7 12.9 -8.7 1.3
092
1100
440E 6.8 11.8 -13.1 -3.1
5000 6.8 11.8 -11.6 -1.6
5800 6.8 11.8 -9.8 0.2
2500
130
440E 3.6 0.5 -21.1 -11.1
5000 3.6 2.0 -19.6 -9.6
5800 3.6 3.8 -17.8 -7.8
092
110
440E 3.6 5.5 -21.1 -11.1
5000 3.6 7.0 -19.6 -9.6
5800 3.6 8.8 -17.8 -7.8
250M 147
5000 3.6 1.9 -13.6 -13.6
5800 3.6 3.7 -7.9 -7.9
5800L 3.6 3.7 -7.9 -7.9
250X 172
5000 3.6 1.9 -13.6 -13.6
5800 3.6 3.7 -7.9 -7.9
5800L 3.6 3.7 -7.9 -7.9
Data for the following figure is found in Table 6, p. 14
and Table 7, p. 14.
