CGWF-SVX01A-EN 15
General Information
Table 4 General Data CCAF
CCAF
Unit Tonnage 202530 4050 60
General
Refrigerant Type R-22 R-22 R-22 R-22 R-22 R-22
Refrigerant Charge lb(kg) Field Field Field Field Field Field
Oil Type Oil 31 Oil 31 Oil 31 Oil 31 Oil 31 Oil 31
Oil Charge Pints(l) 16 (7.6) 22 (10.4) 28 (13.2) 16/16
(7.6/7.6)
22/22
(10.4/10.4)
28/28
(13.2/13.2)
Operating Weight lb(kg) 1004 (456) 1079 (490) 1274 (579) 1509 (685) 1808 (821) 1982 (900)
Shipping Weight lb(kg) 1430 (649) 1605 (729) 1836 (834) 1792 (814) 2166 (984) 2494 (1133)
Overall Dimensions
Length in (mm) 80.1 (2035) 80.1 (2035) 80.1 (2035) 102.6 (2607) 102.6 (2607) 102.6 (2607)
Width in (mm) 29.4 (745) 29.4 (745) 29.4 (745) 31.4 (591) 31.4 (591) 31.4 (591)
Height in (mm) 57.8 (1467) 57.8 (1467) 57.8 (1467) 57.8 (1487) 57.8 (1487) 57.8 (1487)
Evaporator
Water Storage gal (l) 11.7 (44) 10.7 (40) 16.4 (62) 25.7 (97) 24 (90) 39.9 (151)
Minimum Flow gpm (l/s) 24 (1.5) 30 (1.9) 36 (2.3) 48 (3.0) 60 (3.8) 84 (5.3)
Maximum Flow gpm (l/s) 72 (4.5) 90 (5.7) 108 (6.8) 144 (9.1) 180 (11.4) 252 (15.9)
All weights ±3%
Operating weights include refrigerant, oil, and water charges.
