Sound power levels
Discharge
Measurement conditions:
Measurements taken in a room adjacent to the room containing the FWD, at the outlet of the rectangular duct (1.5 m
long) fixed to its discharge opening.
Fan Power level in dB(A), per Hz frequency band Overall power
Unit speed 125 250 500 1000 2000 4000 8000 dB(A)
1 55 50 42 37 37 31 30 46
FWD 08 2 57 54 47 40 30 38 40 50
3 58 57 50 42 32 40 43 53
1 57 51 45 42 34 33 28 48
FWD 10 2 58 54 48 45 38 39 35 51
3 60 58 50 48 40 42 39 54
1 57 51 45 42 34 33 28 48
FWD 12 2 58 54 48 45 38 39 35 51
3 60 58 50 48 40 42 39 54
1 56 62 50 48 39 38 36 56
FWD 14 2 61 66 55 53 47 46 45 60
3 63 69 58 56 50 50 49 63
1 57 63 51 49 40 39 37 57
FWD 20 2 61 66 55 53 47 46 45 60
3 63 69 58 56 50 50 49 63
Intake
Measurement conditions:
Measurements taken at the horizontal air intake.
Fan Power level in dB(A), per Hz frequency band Overall power
Unit speed 125 250 500 1000 2000 4000 8000 dB(A)
1 56 55 55 53 46 45 42 57
FWD 08 2 63 62 60 60 53 53 53 64
3 66 65 63 62 56 55 57 67
1 62 58 55 58 51 48 44 61
FWD 10 2 66 63 60 62 56 55 52 66
3 70 67 63 65 59 59 57 69
1 62 58 55 58 51 48 44 61
FWD 12 2 66 63 60 62 56 55 52 66
3 70 67 63 65 59 59 57 69
1 66 65 65 65 57 50 46 68
FWD 14 2 73 72 69 71 64 59 57 74
3 78 76 73 75 69 64 63 78
1 68 72 64 64 56 52 50 69
FWD 20 2 76 76 68 71 65 61 61 75
3 78 79 71 74 69 66 66 78
CXAX
036
SE-SN
CXAX
039
SE-SN
CXAX
040
SE-SN
CXAX
045
SE-SN
CXAX
046
SE-SN
CXAX
052
SE-SN
CXAX
060
SE-SN
Net cooling capacity R410a (1)
(kW)
95.9
109.9 114.8 119.2 127.9 143.7 155.3
Total Power input in cooling R410a (1)
(kW)
32.6
36.9 37.4 42.1 43.4 49.7 56.7
Net cooling capacity R454B (1) (kW) 92.8 105.2 109.3 116.2 123.3 136.2 154.5
Total Power input in cooling R454B (1) (kW) 29.7 34.0 37.2 37.9 42.1 45.6 51.7
Unit electrical data (2) (3) (4)
Short Circuit Unit Capacity (9) (kA)
15
15 15 15 15 15 15
Power Cable Cross Section (max) mm²
150
150 150 150 150 150 150
Disconnect switch size (A)
250
250 250 250 250 250 250
Digit 12=1 and Digit 15=A
Maximum Power input (kW)
43.0
49.0 51.6 55.5 59.0 66.5 74.0
Unit rated amps (A)
73.8
81.0 90.4 95.8 100.6 110.8 127.6
Unit start up amps (w/o soft starter - Digit 26=A) (4) (A)
197.9
213.7 212.2 221.3 233.3 243.5 253.1
Unit start up amps (with soft starter - Digit 26=B) (4)
139.1
150.5 155.4 159.3 170.1 180.3 191.1
Power factor
0.854
0.886 0.836 0.847 0.861 0.880 0.847
Digit 12=1 and Digit 15=C
Maximum Power input (kW)
44.1
50.0 53.7 56.6 61.2 68.6 76.1
Unit rated amps (A)
74.6
81.8 91.9 96.6 102.1 112.3 129.1
Unit start up amps (w/o soft starter - Digit 26=A) (4) (A)
198.7
214.5 213.7 222.1 234.8 245.0 254.6
Unit start up amps (with soft starter - Digit 26=B) (4)
139.9
151.3 156.9 160.1 171.6 181.8 192.6
Power factor
0.864
0.894 0.854 0.855 0.875 0.892 0.859
Compressor
Compressor Number per Circuit #
3
3 2 3 2 2 2
Type
Scroll
Scroll Scroll Scroll Scroll Scroll Scroll
Model Circuit1 / Circuit 2
12+12+12
13+13+13
10+10 /
10+10
15+15+15
10+13
/10+13
13+13 /
13+13
15+15 /
15+15
Max Compr Power input Circuit 1/Circuit 2 kW
13.7 +
13.7 + 13.7
15,7 +
15.7 + 15.7
12 + 12 /
12 + 12
17.6 +
17.6 + 17.6
12 + 15.7 /
12 + 15.7
15.7 + 15.7 /
15.7 + 15.7
17.6 + 17.6 /
17.6 + 17.6
Rated Amps Circuit1 / Circuit 2 (4) (A)
22.9 +
22.9 + 22.9
25.3 +
25.3 + 25.3
20.2 + 20.2 /
20.2 + 20.2
29.5 +
29.5 + 29.5
20.2 + 25.3 /
20.2 + 25.3
25.3 + 25.3 /
25.3 + 25.3
29.5 + 29.5 /
29.5 + 29.5
Locked Rotor Amps Circuit1 / Circuit 2 (4) (A)
147 +
147 + 147
158 +
158 + 158
142 + 142 /
142 + 142
155 +
155 + 155
142 + 158 /
142 + 158
158 + 158 /
158 + 158
155 + 155 /
155 + 155
Motor RPM (rpm)
2900
2900 2900 2900 2900 2900 2900
Oil sump heater Circuit1 / Circuit 2 (W)
0.25 / 0
0.25 / 0 0.17 / 0.17 0.25 / 0 0.17 / 0.17 0.17 / 0.17 0.17 / 0.17
Evaporator
Quantity #
1
1 1 1 1 1 1
Type Stainless steel Copper Brazed plate Heat exchanger
Evaporator model
P120Tx104
P120Tx104 DP300x82 P120Tx104 DP300x82 DP300x114 DP300x114
Evaporator Water Content volume (l)
12.5
12.5 8.5 12.5 8.5 11.8 11.8
Nominal water connection size (Grooved coupling) -
Without HYM
(in) -
(mm)
2" - 60.3
2" - 60.3 3" OD - 76.1 2" - 60.3 3" OD - 76.1 3" OD - 76.1 3" OD - 76.1
Nominal water connection size (Grooved coupling) -
With HYM
(in) -
(mm)
3" OD - 76.1
3" OD - 76.1 3" OD - 76.1 3" OD - 76.1 3" OD - 76.1 3" OD - 76.1 3" OD - 76.1
Hydraulic Module Components
Single pump - Standard head pressure option
Max available Head Pressure (kPa)
103
131 133 104 114 113 178
Motor Power (kW)
1.50
2.30 2.30 2.30 2.30 2.30 2.30
Rated Amps (A)
3.50
5.03 5.03 5.03 5.03 5.03 5.03
Single pump - High head pressure option
Max available Head Pressure (kPa)
190
176 179 151 162 162 138
Motor Power (kW)
3.00
3.00 3.00 3.00 3.00 3.00 3.00
Rated Amps (A)
6.23
6.23 6.23 6.23 6.23 6.23 6.23
Twin pump - Standard head pressure option
Max available Head Pressure (kPa)
103
131 133 104 114 113 178
Motor Power (kW)
1.50
2.30 2.30 2.30 2.30 2.30 2.30
Rated Amps (A)
3.50
5.03 5.03 5.03 5.03 5.03 5.03
Twin pump - High head pressure option
Max available Head Pressure (kPa)
190
176 179 151 162 162 138
Motor Power (kW)
3.00
3.00 3.00 3.00 3.00 3.00 3.00
Rated Amps (A)
6.23
6.23 6.23 6.23 6.23 6.23 6.23
Expansion Tank Volume (l)
35
35 35 35 35 35 35
Max User water loop Volume for factory mounted
expansion tank (1)
(l)
2000
2000 2000 2000 2000 2000 2000
OptionnalwaterBuertankvolume (l)
444
444 444 444 444 444 444
Antifreeze Heater without pump package (W)
180
180 120 180 120 180 180
Antifreeze Heater with pump package (W)
340
340 280 340 280 340 340
Condenser
Type Full aluminum Micro channel heat exchanger
Quantity of coil #
2
2 2 2 2 2 2
Face area per circuit (m²)
4.46
5.93 2.96 5.93 2.96 2.96 2.96
General Data
Table 4 - CXAX 036-060 General Data
