General
Information
Installation Overview
For convenience, Table 1 summarizes responsibilities that are typically associated with the CVGF chiller
installation process.
Table 1. Installation responsibility chart for CVGF units
Requirement Trane-supplied, Trane-supplied, Field-supplied,
Trane-installed Field-installed Field-installed
Rigging Safety chains
Clevis connectors
Isolation Isolation pads Spring isolators
Spring isolators
Electrical
Terminal lugs
Ground connection(s)
Jumper bars
BAS wiring (optional)
IPC wiring
Control voltage wiring
Optional relays and wiring
Water piping Thermometers
Pressure Relief Relief valves
Insulation Insulation (optional) Insulation
Lifting beam equipment, skates,
rollers, and other lifting
operations
Circuit breakers or non-fused
disconnects (optional)
Circuit breakers or fusible
disconnects (optional)
Temperature sensor
(optional outdoor air)
Remote-mounted starter
(optional)
Chilled-water-pump contactor and
wiring
Condenser-water-pump contactor
and wiring
Flow switches (may be
field-supplied)
Water flow pressure gauges
Isolation and balancing valves
water piping
Pressure relief valves (for water
boxes as
required)
Vent line and flexible connector
Unit-mounted starter
(optional)
Vent and drain valves
