Trane CVGF-SVN02B-E4 - Page 16

Table 2. General data: 400 and 500 ton units
Nominal Tonnage 400 400 400 400 500 500 500 500
1.0 1.0 0.75 0.75 1.0 1.0 0.75 0.75
Two Three Two Three Two Three Two Three
Refrigerant Type R134a R134a R134a R134a R134a R134a R134a R134a
Refrigerant Charge - 650 650 650 650 750 750 750 750
pounds (kg) (295) (295) (295) (295) (295) (295) (295) (295)
Oil Charge 15 15 15 15 15 15 15 15
(gallon (l)) (56.8) (56.8) (56.8) (56.8) (56.8) (56.8) (56.8) (56.8)
Overall Dimensions - Feet-Inch (mm)
Length 15'- 10 13/16" 15'- 10 13/16" 15'- 10 13/16" 15'- 10 13/16" 15'- 10 13/16" 15'- 10 13/16" 15'- 10 13/16" 15'- 10 13/16"
(4800) (4800) (4800) (4800) (4800) (4800) (4800) (4800)
Width 6' - 6 19/64" 6' - 6 19/64" 6' - 6 19/64" 6' - 6 19/64" 6' - 6 19/64" 6' - 6 19/64" 6' - 6 19/64" 6' - 6 19/64"
(1989) (1989) (1989) (1989) (1989) (1989) (1989) (1989)
Height 6' - 10 1/2" 6' - 10 1/2" 6' - 10 1/2" 6' - 10 1/2" 6' - 10 1/2" 6' - 10 1/2" 6' - 10 1/2" 6' - 10 1/2"
(2096) (2096) (2096) (2096) (2096) (2096) (2096) (2096)
2' - 7 1/8" 2' - 7 1/8" 2' - 7 1/8" 2' - 7 1/8" 2' - 7 1/8" 2' - 7 1/8" 2' - 7 1/8" 2' - 7 1/8"
(791) (791) (791) (791) (791) (791) (791) (791)
8" 8" 8" 8" 8" 8" 8" 8"
(203) (203) (203) (203) (203) (203) (203) (203)
2' - 1 1/2" 2' - 1 1/2" 2' - 1 1/2" 2' - 1 1/2" 2' - 1 1/2" 2' - 1 1/2" 2' - 1 1/2" 2' - 1 1/2"
(3060) (3060) (3060) (3060) (3060) (3060) (3060) (3060)
10" 10" 10" 10" 10" 10" 10" 10"
(254) (254) (254) (254) (254) (254) (254) (254)
Weight - pounds (kg)) except Waterboxes
Compressor/Motor 6220 6220 6220 6220 6220 6220 6220 6220
(2821) (2821) (2821) (2821) (2821) (2821) (2821) (2821)
Evaporator 3948 3948 4228 4228 4193 4193 4568 4568
(1791) (1791) (1918) (1918) (1902) (1902) (2072) (2072)
Condenser 2857 2857 3472 3472 3152 3152 3877 3877
(1296) (1296) (1575) (1575) (1430) (1430) (1759) (1759)
Economizer 535 535 535 535 535 535 535 535
(243) (243) (243) (243) (243) (243) (243) (243)
Starter Panel 500 500 500 500 500 500 500 500
(227) (227) (227) (227) (227) (227) (227) (227)
Control Panel 70 70 70 70 70 70 70 70
(318) (318) (318) (318) (318) (318) (318) (318)
2127 2127 2127 2127 2127 2127 2127 2127
(965) (965) (965) (965) (965) (965) (965) (965)
17867 17867 17867 17867 17867 17867 17867 17867
(8104) (8104) (8104) (8104) (8104) (8104) (8104) (8104)
21460 21460 21460 21460 22564 22564 22564 22564
(9734) (9734) (9734) (9734) (10235) (10235) (10235) (10235)
Operational Data
447 298 407 271 550 367 511 340
(28) (20) (25.6) (17) (34) (23) (32) (21)
1638 1092 1493 995 2018 1346 1873 124895
(103) (69) (94) (63) (127) (85) (118) (79)
499 499 487 487 606 606 586 586
(31) (31) (31) (31) (38) (38) (37) (37)
1831 1831 1786 1786 2221 2221 2148 2148
(115) (115) (113) (113) (140) (140) (135) (135)
CVGF-SVN02B-E4
16
General
Information
Evaporator Water Pass
Evaporator Water
Connection (NPS)
Condenser Nominal
Connector Size (NPS)
Miscellaneous Item
Minimum Evaporator
Flow in gpm (l/sec)
Maximum Evaporator
Flow in gpm (l/sec)
Minimum Condenser
Flow in gpm (l/sec)
Maximum Condenser
Flow in gpm (l/sec)
Tube Outside Diameter
(inch)
Evaporator Inside
Diameter
Condenser Inside
Diameter
Shipping Weight
Operating Weight
