Trane CVGF-SVN02B-E4 - Page 19

CVGF-SVN02B-E4
19
General
Information
Table 3. General data: 650 ton units (continued)
Nominal Tonnage 650
1.0 0.75
Two Three Two Three
Water Volume - 150 pound Waterboxes
163.2 158.2 154.1 149.1
(618) (599) (583) (564)
185.1 185.1 188.5 188.5
(701) (701) (714) (714)
Evaporator 2-pass Weight
Supply - pound 304 304 304 304
(kg) (138) (138) (138) (138)
Return - pound 337 337 337 337
(kg) (153) (153) (153) (153)
Evaporator 3-pass Weight
Supply - pound 314 314 314 314
(kg) (142) (142) (142) (142)
Return - pound 332 332 332 332
(kg) (151) (151) (151) (151)
Condenser 2-pass Weight
Supply - pound 304 304 304 304
(kg) (138) (138) (138) (138)
Return - pound 341 341 341 341
(kg) (155) (155) (155) (155)
300 pound Waterboxes
163.2 158.2 154.1 149.1
(618) (599) (583) (564)
185.1 185.1 189.4 189.4
(701) (701) (717) (717)
Evaporator 2-pass Weight
Supply - pound 427 427 427 427
(kg) (194) (194) (194) (194)
Return - pound 446 446 446 446
(kg) (202) (202) (202) (202)
Evaporator 3-pass Weight
Supply - pound 448 448 448 448
(kg) (203) (203) (203) (203)
Return - pound 448 448 448 448
(kg) (203) (203) (203) (203)
Condenser 2-pass Weight
Supply - pound 421 421 421 421
(kg) (191) (191) (191) (191)
Return - pound 436 436 436 436
(kg) (198) (198) (198) (198)
Evaporator Water
Storage gallon (l)
Condenser Water
Storage gallon (l)
Evaporator Water
Storage (gallon (l))
Condenser Water
Storage gallon (l)
Evaporator Water Pass
Tube Outside
Diameter (inch)
