General
Information
Table 5. General data: 800 ton units (continued)
Nominal Tonnage 800
1.0 0.75
Two Three Two Three
Water Volume - 150 pound Waterboxes
190.4 185.4 177.4 172.4
(721) (702) (672) (653)
213.5 213.5 218.0 218.0
(808) (808) (828) (828)
Evaporator 2-pass Weight
Supply - pound 303.57 303.57 303.57 303.57
(kg) (137.7) (137.7) (137.7) (137.7)
Return - pound 337.16 337.16 337.16 337.16
(kg) (152.9) (152.9) (152.9) (152.9)
Evaporator 3-pass Weight
Supply - pound 313.56 313.56 313.56 313.56
(kg) (142.2) (142.2) (142.2) (142.2)
Return - pound 331.72 331.72 331.72 331.72
(kg) (150.5) (150.5) (150.5) (150.5)
Condenser 2-pass Weight
Supply - pound 303.69 303.69 303.69 303.69
(kg) (137.8) (137.8) (137.8) (137.8)
Return - pound 340.67 340.67 340.67 340.67
(kg) (154.5) (154.5) (154.5) (154.5)
300 pound Waterboxes
190.4 185.4 177.4 172.4
(721) (702) (672) (653)
214.5 214.5 219.0 219.0
(812) (812) (829) (829)
Evaporator 2-pass Weight
Supply - pound 426.69 426.69 426.69 426.69
(kg) (193.5) (193.5) (193.5) (193.5)
Return - pound 446.20 446.20 446.20 446.20
(kg) (202.4) (202.4) (202.4) (202.4)
Evaporator 3-pass Weight
Supply - pound 447.81 447.81 447.81 447.81
(kg) (203.1) (203.1) (203.1) (203.1)
Return - pound 447.98 447.98 447.98 447.98
(kg) (203.2) (203.2) (203.2) (203.2)
Condenser 2-pass Weight
Supply - pound 421.43 421.43 421.43 421.43
(kg) (191.2) (191.2) (191.2) (191.2)
Return - pound 436.11 436.11 436.11 436.11
(kg) (197.8) (197.8) (197.8) (197.8)
Evaporator Water Pass
Evaporator Water Storage
gallon (l)
Condenser Water Storage
gallon (l)
Evaporator Water Storage
gallon (l)
Condenser Water Storage
gallon (l)
Tube Outside Diameter
(inch)
