Trane CVGF-SVN02B-E4 - Page 27

CVGF-SVN02B-E4
27
General
Information
Table 6. General data: 1000 ton family (continued)
Bundle C C C C D D D D
1.0 1.0 0.75 0.75 1.0 1.0 0.75 0.75
Two Three Two Three Two Three Two Three
Overall Dimensions - Feet-Inch (mm)
Length 17' - 5 13/32" 17' - 5 13/32" 17' - 5 13/32" 17' - 5 13/32" 17' - 5 13/32" 17' - 5 13/32" 17' - 5 13/32" 17' - 5 13/32"
(5320) (5320) (5320) (5320) (5320) (5320) (5320) (5320)
Width 7' - 6 39/64" 7' - 6 39/64" 7' - 6 39/64" 7' - 6 39/64" 7' - 6 39/64" 7' - 6 39/64" 7' - 6 39/64" 7' - 6 39/64"
(2301) (2301) (2301) (2301) (2301) (2301) (2301) (2301)
Height 8' - 4" 8' - 4" 8' - 4" 8' - 4" 8' - 4" 8' - 4" 8' - 4" 8' - 4"
(2540) (2540) (2540) (2540) (2540) (2540) (2540) (2540)
3' 7 3/4" 3' 7 3/4" 3' 7 3/4" 3' 7 3/4" 3' 7 3/4" 3' 7 3/4" 3' 7 3/4" 3' 7 3/4"
(1111) (1111) (1111) (1111) (1111) (1111) (1111) (1111)
12" 10" 12" 10" 12" 10" 12" 10"
(305) (250) (305) (250) (305) (250) (305) (250)
2' - 11 1/4" 2' - 11 1/4" 2' - 11 1/4" 2' - 11 1/4" 2' - 11 1/4" 2' - 11 1/4" 2' - 11 1/4" 2' - 11 1/4"
(895) (895) (895) (895) (895) (895) (895) (895)
14" 14" 14" 14" 14" 14" 14" 14"
(356) (356) (356) (356) (356) (356) (356) (356)
Weight - pounds (kg) 150 pound Waterboxes
9493 9493 9493 9493 9493 9493 9493 9493
(4306) (4306) (4306) (4306) (4306) (4306) (4306) (4306)
7537 7537 8190 8190 7787 7787 8474 8474
(3419) (3419) (3715) (3715) (3532) (3532) (3844) (3844)
6571 6571 7707 7707 6816 6816 8148 8148
(2981) (2981) (3496) (3496) (3092) (3092) (3696) (3696)
1461 1461 1461 1461 1461 1461 1461 1461
(663) (663) (663) (663) (663) (663) (663) (663)
Evaporator Water pass
Evaporator Water
Connection size (NPS)
Condenser Nominal
Connector size (NPS)
Compressor
weight
Evaporator weight
Condenser weight
Economizer weight
Condenser Inside
Diameter
Tube Outside
Diameter (inch)
Evaporator Inside
Diameter
