General
Information
Table 6. General data: 1000 ton family (continued)
Bundle C C C C D D D D
1.0 1.0 0.75 0.75 1.0 1.0 0.75 0.75
Two Three Two Three Two Three Two Three
542 542 542 542 542 542 542 542
(246) (246) (246) (246) (246) (246) (246) (246)
70 70 70 70 70 70 70 70
(318) (318) (318) (318) (318) (318) (318) (318)
1430 1430 1439 1439 1430 1430 1439 1439
(649) (649) (653) (653) (649) (649) (653) (653)
3222 3274 3222 3274 3222 3274 3222 3274
(1461) (1485) (1461) (1485) (1461) (1485) (1461) (1485)
520 520 520 520 520 520 520 520
(236) (236) (236) (236) (236) (236) (236) (236)
32101 32153 34189 34241 32639 32691 34656 34708
(14561) (14584) (15508) (15531) (14805) (14828) (15720) (15743)
4405 4353 4411 4359 4686 4635 4599 4547
(1998) (1974) (2001) (1977) (2126) (2102) (2086) (2062)
1447 1447 1447 1447 1497 1497 1497 1497
(656) (656) (656) (656) (679) (679) (679) (679)
37953 37953 40047 40047 38822 38823 40752 40752
(17215) (17215) (18165) (18165) (17609) (17610) (18484) (18485)
Starter panel
weight - pound
(kg)
Evaporator
Water pass
Control panel
weight - pound
(kg)
I/C Piping and
Supports - pound
(kg)
Miscellaneous
Item - pound (kg)
Total Water
Volume - pound
(kg)
Refrigerant and
Oil - pound (kg)
Total Shipping -
pound (kg)
Tube Outside
Diameter (inch)
Waterboxes -
pound (kg)
Total Weight -
pound (kg)
