Trane CVGF-SVN02B-E4 - Page 31

CVGF-SVN02B-E4
31
General
Information
Table 6. General data: 1000 ton family (continued)
Bundle C C C C D D D D
1.0 1.0 0.75 0.75 1.0 1.0 0.75 0.75
Two Three Two Three Two Three Two Three
1325 1325 1325 1325 1375 1375 1375 1375
(601) (601) (601) (601) (624) (624) (624) (624)
15 15 15 15 15 15 15 15
(56.8) (56.8) (56.8) (56.8) (56.8) (56.8) (56.8) (56.8)
1003 669 1021 681 1115 744 1136 757
(3797) (2532) (3865) (2578) (4221) (2816) (4300) (2866)
3678 2452 3745 2497 4090 2726 4165 2777
(13923) (9282) (14176) (9452) (15482) (10319) (15766) (10512))
1192 1192 1176 1176 1307 1307 1213 1213
(4512) (4512) (4452) (4452) (4948) (4948) (4592) (4592)
4372 4372 4311 4311 4792 4792 4447 4447
(16550) (16550) (16319) (16319) (18140) (18140) (16834) (16834)
150 pound waterboxes
249.7 243.5 252.4 246.2 266.5 260.4 269.5 263.3
(945.2) (921.7) (955.4) (932.0) (1009) (985.7) (1020) (996.7)
278.3 278.3 276.3 276.3 295.2 295.2 281.8 281.8
(1054) (1054) (1046) (1046) (1118) (1118) (1067) (1067)
Evaporator 2-pass Weight
Supply - pound 849.3 849.3 849.3 849.3 849.3 849.3 849.3 849.3
(kg) (385.2) (385.2) (385.2) (385.2) (385.2) (385.2) (385.2) (385.2)
Return - pound 758.2 758.2 758.2 758.2 758.2 758.2 758.2 758.2
(kg) (343.9) (343.9) (343.9) (343.9) (343.9) (343.9) (343.9) (343.9)
Evaporator 3-pass Weight
Supply - pound 827.1 827.1 827.1 827.1 827.1 827.1 827.1 827.1
(kg) (375.2) (375.2) (375.2) (375.2) (375.2) (375.2) (375.2) (375.2)
Return - pound 831.8 831.8 831.8 831.8 831.8 831.8 831.8 831.8
(kg) (377.3) (377.3) (377.3) (377.3) (377.3) (377.3) (377.3) (377.3)
Condenser 2-pass Weight
Supply - pound 854.2 854.2 854.2 854.2 854.2 854.2 854.2 854.2
(kg) (387.5) (387.5) (387.5) (387.5) (387.5) (387.5) (387.5) (387.5)
Return - pound 760.8 760.8 760.8 760.8 760.8 760.8 760.8 760.8
(kg) (345.1) (345.1) (345.1) (345.1) (345.1) (345.1) (345.1) (345.1)
300 pound Waterboxes
250.2 243.9 252.9 246.6 267 260.7 270 263.7
(947.1) (923.3) (957.3) (933.5) (1011) (986.9) (1022) (998.2)
278.9 278.9 276.9 276.9 295.9 295.9 282.4 282.4
(1056) (1056) (1048) (1048) (1120) (1120) (1069) (1069
Evaporator 2-pass Weight
Supply - pound 1041.7 1041.7 1041.7 1041.7 1041.7 1041.7 1041.7 1041.7
(kg) (472.5) (472.5) (472.5) (472.5) (472.5) (472.5) (472.5) (472.5)
Return - pound 983.5 983.5 983.5 983.5 983.5 983.5 983.5 983.5
(kg) (446.1) (446.1) (446.1) (446.1) (446.1) (446.1) (446.1) (446.1)
Evaporator 3-pass Weight
Supply - pound 1041.7 1041.7 1041.7 1041.7 1041.7 1041.7 1041.7 1041.7
(kg) (472.5) (472.5) (472.5) (472.5) (472.5) (472.5) (472.5) (472.5)
Return - pound 1045.7 1045.7 1045.7 1045.7 1045.7 1045.7 1045.7 1045.7
(kg) (474.3) (474.3) (474.3) (474.3) (474.3) (474.3) (474.3) (474.3)
Condenser 2-pass Weight
Supply - pound 1004.8 1004.8 1004.8 1004.8 1004.8 1004.8 1004.8 1004.8
(kg) (455.8) (455.8) (455.8) (455.8) (455.8) (455.8) (455.8) (455.8)
Return - pound 986.1 986.1 986.1 986.1 986.1 986.1 986.1 760.8
(kg) (447.3) (447.3) (447.3) (447.3) (447.3) (447.3) (447.3) (447.3)
Note: Immediately report any unit damage incurred during handling or installation at the job site to Trane sales office.
Refrigerant Oil charge -
pound (kg)
Evaporator Water
pass
Oil charge -
gallons (l)
Mininum Evaporator
Flow - GPM (l/s)
Maximum Evaporator
Flow - GPM (l/s)
Minimum Condenser
flow - GPM (l/s)
Maximum Condenser
flow - GPM (l/s)
Evaporator Water
Storage - gallons (l)
Condenser Water
Storage - gallons (l)
Evaporator Water
Storage - gallons (l)
Condenser Water
Storage - gallons (l)
Tube Outside Diameter
(inch)
