Installation:
Mechanical
Water Pressure Drop Data
Pressure drop for CVGF 500 Evaporators with 1.0 inch OD
tubes and 2 pass waterboxes
Flow (in GPM)
Pressure drop for CVGF 500 Condensers with 1.0 inch OD
tubes and 2 pass waterboxes
Pressure drop (in feet of water)
Flow (in GPM)
Pressure drop (in feet of water)
Graph 3.
Graph 4.
Bundle C
Bundle A
Bundle B
Bundle C
Bundle A
Bundle B
