CVGF-SVN02B-E4
63
Installation:
Electrical
Figure 18. Terminal stud, clamp and lug assembly
Belleville
washer
3/8"* Bolt
Terminal
lugs
Belleville
washer
Motor
terminal
stud
Terminal
clamp
Front View
Mid Voltage
RXL RATR RPIR CXL CATR CPIR
