Loose Parts Inventory
The loose parts items ship in the
motor junction box for units
without a unit-mounted starter,
or in the starter panel for units
equipped with a unit-mounted
starter. This includes the
isolation pads, extra oil filter,
and any optional factory-shipped
items.
Unit Description
The CVGF units are single-
compressor, gear-type, water-
cooled liquid chillers designed
for installation indoors. Each unit
is a completely assembled,
hermetic package that is factory-
piped, wired, leak-tested,
dehydrated, oil-charged, and
tested for proper control
operation before shipment.
Note: high-voltage starters are
not unit-mounted before
shipment.
Figure 2 and Figure 3 show a
typical CVGF unit and its
components. Water inlet and
outlet openings are covered
before shipment. The oil tank is
factory-charged with 15 gallons
(56.8L) of Trane Oil 37 and a
holding charge of 5 psig (34 kPa)
of dry nitrogen at 70°F (21°C).
(See the Operation Maintenance
Manual for equivalent oil
specification.)
CVGF-SVN02B-E4
7
General
Information
