Unit Control
Panel (UCP)
Chiller
Description Units notes
1. Front Panel Control Type (Chilled Water, Hot Water), Chilled Water default
2. Front Panel Chilled Water Setpoint Temperature 1
3. Front Panel Current Limit Setpoint Percent 2
4. Front Panel Base Load Command On or Auto
6. Front Panel Base Load Setpoint Percent
6. Differential to Start Temperature
7. Differential to Stop Temperature
8. Setpoint Source (none, use front panel, override BAS), none default
Feature Settings
Description Units
1. Chilled Water Reset (Constant, Outdoor, Return, Disable), Disable Percent
2. Return Reset Ratio Temperature
3. Return Start Reset Temperature
4. Return Maximum Reset Temperature
5. Outdoor Reset Ratio Percent
6. Outdoor Start Reset Temperature
7. Outdoor Maximum Reset Temperature
8. External Chilled Water Setpoint (Enable, Disable), Disable
9. External Current Limit Setpoint (Enable, Disable), Disable
10. External Base Loading Setpoint (Enable, Disable), Disable
Notes:
1. Temperatures will be adjustable to 0.1 degree F or C. The Main Processor provides the minimum and maximum allowable value.
2. Adjustable to the nearest whole number percent. The Main Processor provides the minimum and maximum allowable value.
