CVGF-SVU02B-E4
38
Unit Control
Panel (UCP)
Mode Overrides
Description Units Default Monitor Value Notes
1. Compressor Control Signal (Auto, Manual) Auto Percent Vane Position
[0-100] )
7
2. Evaporator Water Pump (Auto, On), Auto 1) Evaporator Flow status
2) Override Time Remaining 3
3. Condenser Water Pump (Auto, On), Auto 1) Condenser Flow status
2) Override Time Remaining 3
4. Oil Pump (Auto, On), Auto 1) Differential pressure
2) Override Time Remaining 3
5. Clear Restart Inhibit Timer
Display Settings
Description Units Notes
1. Date Format (“mmm dd, yyyy”, “dd-mmm-yyyy”),
2. Date “mmm dd, yyyy” 4
3. Time Format (12-hour, 24-hour), 12-hour
4. Time of Day HH:mm 4
5. Keypad and Display Lockout (Enable, Disable), Disable 5
6. Display Units (SI, English), English
7. Pressure Units Absolute / Guage
8. Language (English, Selection 2, Selection 3), English 6
Notes:
3. Terminates with 10 minutes if inactivity.
4. The Date and Time setup screen formats deviate slightly from the standard screens defined above. See the time and date section for further details.
5. Enables a DynaView
™
Lockout screen. All other screens timeout in 30 minutes to this screen when enabled. The DynaView
™
Lockout Screen displays
a 0-9 keypad to permit the user to exit the lockout with a fixed password (1x5 x 9 + Enter). See lockout section for further details.
6. Language choices are dependent on what has been setup in the Main Processor. Language selections will include English and two alternate as
loaded by TechView
™
. Language shall always be the last setting listed on the Display Settings menu. This will allow a user to find language selection
if looking at an unrecognizable language.
7. Manual Compressor Control allows an operator to override the Auto Control and manually control the compressor while in operation. This is not
active during Stop mode.
Evaporator Leaving Water
Temperature
