Model number digits are selected and assigned in accordance with the following definitions using the
typical model number example shown below:
CVGF0500HA0C31609005B1B5B1C2306G4A1E2CC0A0CL
C = (1st digit)
V = (2nd digit) Hermetic Centrifugal Compressor
G = (3rd digit) Gear Drive
F = (4th digit) Development sequence
0500 = (5th, 6th, 7th, and 8th digit) Nominal compressor tonnage
0400 = 400 tons
0500 = 500 tons
0650 = 650 tons
0800 = 800 tons
1000 = 1000 tons
SSSS = Special
H = (9th digit) Unit Voltage
D = 380V-60 Hz
F = 460V-60 Hz
H = 575V-60 Hz
N = 4160V-60 Hz
P = 3300V-60 Hz
R = 380V-50 Hz
T = 400V-50 Hz
U = 415V-50 Hz
V = 3300V-50 Hz
X = 6600V-60 Hz
Z = 6600V-50 Hz
S = Special
A0 = (10th and 11th digit) Design Sequence
C = (12th digit) Control Enclosure
C = Standard Control Enclosure
S = Special
316 = (13th, 14th, and 15th digit) Compressor Motor Power (kw)
221 = 221 CPKW
254 = 254 CPKW
285 = 285 CPKW
316 = 316 CPKW
357 = 357 CPKW
401 = 401 CPKW
240 = 240 CPKW
266 = 266 CPKW
301 = 301 CPKW
338 = 338 CPKW
374 = 374 CPKW
430 = 430 CPKW
444 = 444 CPKW
484 = 484 CPKW
511 = 511 CPKW
532 = 532 CPKW
574 = 574 CPKW
594 = 594 CPKW
641 = 641 CPKW
CVGF-SVX03B-EN
10
General Information
