Figure 6. Compressor cross-section view
Motor rotor
Motor shaft
Bull gear
Discharge end
Suction
end
Motor terminal
Motor
housing
Motor stator
Pinion shaft
Gear housing
2nd stage
impeller
Oil pump
1st stage
impeller
Oil
sump
CVGF-SVX03B-EN
36
General Information
