Installation: Electrical
Figure 30. Terminal stud, clamp and lug assembly
Belleville
washer
3/8"* Bolt
Terminal
lugs
Belleville
washer
Motor
terminal
stud
Terminal
clamp
Front View
Mid V
oltage
RXL RATR RPIR CXL CATR CPIR
CVGF-SVX03B-EN
84
